Solare Teknica 5000

Shelter Your Outdoor Area in Style.

Home > Outdoor Exterior Roller Blinds > T5000 Side Retention Zip

Teknica 5000 | Side Retention Exterior Roller Awning

With head box and side channel as standard, the fabric is tensioned by utilising a floating channel, located within the special two piece side channel, eliminating the possibility of fabric “blow outs” or light gaps.

solare teknica

As the fabric is held taught between the left and right channels, this system is ideal for enclosing courtyards, patios or balconies, essentially adding an extra room to the home.

The Solare Teknica 5000 is a great way to shelter courtyards and other outdoor space from wind, insects and UV rays. Enquire with Peter Meyer today or explore more of our great outdoor blinds in Sydney.

Solare Teknica 5000 Side Retention systems Exterior Roller Awning
side retention system exterior roller blinds

Size & Application


Maximum Width:
5m or
Maximum Drop: 4m (up to max. 16 sq.m)

Style: Exterior Roller | SRS | Side Retention System [ Zip System ] Suitability: Windows + Balconies + Alfresco dining rooms

Secure: Locking Bolts
Best for: High Wind Resistance. Approx. wind rating 100km per hr.  Approx. wind rating 100km per hr.  Sun + UV protection. Light & heat control.  Insect Resistant.  Enclosing balcony + creating privacy
Fabrics: Huge collection of Screens and Acrylic Canvas fabrics as well as Clear PVC. Most fabrics available by request.

1. Locking Bolts
The channel end caps essentially push the floating channel up 15mm allowing the locking bolt to insert into the base of the channel.

2. Powder Coated Headbox + Side Channels
4 standard durable powder coated finishes available, & we offer custom powder coating if required.

Teknica 5000 Showcase

Head Box Options

closed headbox

Closed Headbox

Encapsulates the fabric from external elements such as rain, UV and, fragments, which assists in keeping the fabric clean and enhances longevity.

open headbox

Open Headbox

Increase air circulation around the roller minimising heat build up for PVC skins. (Ideal for the Pivot Arm Awning but can  also be used in front rolled Cable Guide and Straight Drop Awnings)

open roller

Open Roller

A modern industrial look for the ideal choice to reduce cost.

Accessories

weight bar

Weight Bar
The heavy duty bottom rail has been designed to offer an additional weight bar, this is beneficial for smaller awnings that require further weight to reduce bottom rail bounce and increase fabric tension.

hold down strap

Hold Down Strap
Hold down straps can be used to hold the awning down at various points across the width of the awning. This option also offers a traditional no guide system where the awning is simply locked into place via straps. Similar to the locking bolts, the hold down clips also insert inside the bottom rail for a clean bottom rail finish.

locking bolt

Locking Bolt
The locking bolt secures the awning into the side channel base cable bracket or breeching staple.

pile brush & valance

Pile Brush and Valance
As experienced in a number of Australian homes, the floor surface is often not perfectly level. Therefore when an awning is installed over a wide width there will be room for: light gaps, insects, debris, wind and rain to enter your courtyard or home. With the ability to insert either pile brush or a fabric valance, this gap canbe eliminated therefore maximising the functionality of the awning. In addition to the protection offered by these inserts they also protect the bottom rail from chipping if dropped to the ground quickly and changing the overall look of the awning based on the valance style chosen.

Fabrics


Air flow

Clear PVC is great for unrestricted view through, however air flow is not an option. If you are enclosing a verandah or patio, consider if you still want to have a nice cool breeze coming through. If this is required ensure to select a open weave fabric with around 10% openness.

Privacy and view through
There are open and closed weave awning fabrics. Consider if you want day or night time privacy. A open weave fabric with in a dark colour gives fantastic view through in the day, but also allows others to see in at night.

Durability
Be mindful that when a fabric is outdoors it is exposed to the elements. Fabrics with Sanitized® Antimicrobial Protection or DURAGUARD® Protection keeps odours away, protects against the development of bacteria, resists stains and stops mildew and fungi build up ensuring freshness in your home.

fabricsColour fastness
Ensure the fabric you choose has excellent fade resistance to the sun. Any fabric with fade resistance result of 6 and above is reptiable and will ensure your fabric remains the colour you selected for many years to come.
a. Mesh
b. Canvas
c. Clear PVC
d. Acrylic

Operating Options

manual crankManual Crank The geared crank ensures easy operation that is not dependant on your strength. Available in a selection of Black, Grey and White for colour co-ordination. The geared crank handles are available in: 800mm, 1200mm, 1600mm, 2000mm and 2400mm lengths to suit any awnings height.

motorisation controlMotorisation

Control your awning with a touch of a button with motorisation. The Solare Teknica range can be used with the latest Automatic Tensioning Motors that permit awnings to be locked in position (with strap or sliding bolt) and tensioned. This maintains tension on the fabric minimising fabric “blow outs” traditionally caused by unexpected high winds.

Downloads

Download our brochures containing all product details and and full technical specifications.

Full Ranges Brochure

Product Brochure

Technical Brochure

Somfy Motorisation. Cutting edge technology

  • Finest quality incorporating cutting edge technology
  • Touch of a button convenience
  • Range of controllers & switching offering great flexibility
  • Can control multiple blinds & awnings from one controller
  • Add sensors & timing to operate while away
  • Energy efficiency by controlling heat & light entering
  • Smooth & controlled movement ensures longer life
  • Quiet, sophisticated & discreet operation. Impress guests
somfy automation controllers

Exceptional Quality + Build Standards



Blinds by Peter Meyer & Weinor ensure:

  • Weinor cutting edge technology & build quality
  • Backed by Peter Meyer’s 5 year warranty
  • Plus the Peter Meyer renowned level of service
